SFP+ Fiber Module
$60.00
Sale price
$60.00
Regular price
Skip to product information
- Hot-pluggable small-form factor transceiver modules integrated with the high sensitivity PIN receiver and signal conditioner for 1.25/10 Gigabit Ethernet applications. SFP modules support very low EMI and excellent ESD protection
- Fiber Mode: Single-Mode Fiber
- Connector Type: Duplex LC
- DDM: 10Gbps SFP+
- Nominal Wavelength: 1310nm
- Data Rate: 10Gbps SFP+
- Max Power Consumption: 1W
- Transfer Distance: 10km
- TX Power: -8.2 to 0.5dBm, ±3dB
- RX Power: -14.4 to 0.5dBm, ±3dB
- Operation Voltage: 3.3V±0.3V
- Environmental: Operation: 0? to 70?,
SFP+ Fiber Module
$60.00
Sale price
$60.00
Regular price
- Fiber Mode: Single-Mode Fiber
- Connector Type: Duplex LC
- DDM: 10Gbps SFP+
- Nominal Wavelength: 1310nm
- Data Rate: 10Gbps SFP+
- Max Power Consumption: 1W
- Transfer Distance: 10km
- TX Power: -8.2 to 0.5dBm, ±3dB
- RX Power: -14.4 to 0.5dBm, ±3dB
- Operation Voltage: 3.3V±0.3V
- Environmental: Operation: 0? to 70?,
